Saddle Fusion Machine MAX1200
Saddle Fusion Machine MAX1200

Categories | Saddle Fusion Machines |
---|---|
Brand | RIYANG |
Model | MAX1200 |
Certificate | CE, ISO9001 |
Packing Material | Plywood Pallet |
MOQ | 1set |
FOB port | Shanghai |
Terms of Payment | L/C, Western Union, T/T, Paypal |
Update Time | Jul 31,2025 |
Detail Information
Saddle Fusion Machine MAX1200
MAX1200 is designed to fabricate reducing tee with various pipe specifications.
This largely fills a vacancy in the coordination of different pipe diameters, which should be applied to special projects.
Product Details
|
|||
WELDING TYPE
|
SADDLE T TYPE
|
APPLIED MATERIAL
|
PE/PP/PVDF
|
APPLICABLE ENVIRONMENT TEMPERATURE | -10 ℃ ~ 45℃ | VOLTAGE | AC 380V, 50/60HZ |
MAX1200 Standard Configuration Table (Unit: mm)
|
|||||||
BRANCH \MAIN | 560 | 630 | 710 | 800 | 900 | 1000 | 1200 |
160
|
√
|
- | - | - | - |
-
|
-
|
200 | √ | √ | √ | - | - | - | - |
225 | √ | √ | √ | √ | - | - | - |
250 | √ | √ | √ | √ | √ | - | - |
280 | √ | √ | √ | √ | √ | √ | - |
315 | - | √ | √ | √ | √ | √ | √ |
355 | - | - | √ | √ | √ | √ | √ |
400 | - | - | - | √ | √ | √ | √ |
450 | - | - | - | - | √ | √ | √ |
500 | - | - | - | - | - | √ | √ |


Featured by
- Suitable for fabricating HDPE reducing tee in a workshop. The integrated function of welding and taping enables to complete of the whole fabricating process.
- A Teflon coated heating plate.
- Separate two-channel timer records times in soaking and cooling phases.
- Digital high-accurate pressure meter indicates exact readings.
- Linear guide ways are equipped with a heating plate and dragging plate.
